With a built-in four output distribution amplifier for audio and video, you can quickly make multiple copies with professional results.

Re-generates all sync signals to stabilize the video.

All four TBC's are synchronized together (internal genlock)

No External Genlock input

Frame synchronization with full frame memory.

Built-in four output distribution amplifier for stereo audio, composite, and Y/C video.

Wide bandwidth, Y/C in 4.5MHz, composite 3.5 MHz Low noise, S.N ratio > 50dB 8-bit video resolution, 4:2:2 sampling rate.


Inputs
4 (A+B+C+D) Y/C (S-Video) 4-pin 75 ohm DIN Connectors
4 (A+B+C+D) Composite (RCA) Video 75 ohm RCA Connectors, Level: 1.0VP-P
Note: Does NOT accept 'house synch' as a reference signal.

Outputs
4 (A+B+C+D) Y/C (S-Video) 4-pin 75 ohm DIN Connectors
4 (A+B+C+D) Composite (RCA) Video 75 ohm RCA Connectors, Level: 1.0VP-P
4 (A+B+C+D) Composite Preview (RCA) Video 75 ohm, Level: 1.0VP-P

Controls
Brightness +/- 10%
Contrast +/- 3dB
Color +/- 3dB
Tint (NTSC only) +/- 5°
Frequency Response 4.5MHz +/- 3dB
DG, DP +/- 2%, 1°
S/N Ratio > 50dB
Processing
Still Field
Component 8-bit, 4:2:2; Y: 13.5 MHz
Correction Range Four Channel Full Frame TBC
Pattern Generator Color Bar Pattern

General
Power 9 VDC 18W (AC adapter included)
Ambient Temperature 32°-131° F (0°-55° C)
Ambient Humidity < 90%

Accessories
Y/C (S-Video), Composite (RCA) Cables & Rack mount brackets.
